21.5” LCD Panel 1920 x 1080 (FHD) ResolutionIP65 aluminum front cover protectionResistive Touch ScreenSupport Display Port/ HDMI / VGADC 12~24V Power inputFeatures
21.5” LCD Panel 1920 x 1080 (FHD) ResolutionIP65 aluminum front cover protectionResistive Touch ScreenSupport Display Port/ HDMI / VGADC 12~24V Power inputApplications
Industrial HMI Display SystemsATM / Self-service / Kiosk ApplicationsVending / Ticketing MachinesPoint-of-information Terminals Factory / Machine Automation| Model | TPM-3521RW | ||||
| Display | Panel Size | 21.5” LCD Panel | |||
| Resolution | 1920 x 1080 (FHD) | ||||
| Viewing Angle | 85 x 85 (H), 80 x 80 (V) | ||||
| Brightness | 250 (cd/m2) | ||||
| Color Support | 16.7 M | ||||
| Contrast Ratio | 3000:1 | ||||
| Response Time | 5 (msec) | ||||
| Touchscreen | Touchscreen Type | 5-wire Resistive | |||
| Surface Hardness | 3 Mohs | ||||
| Transparency | 80% (±3%) | ||||
| I/O Interface | Video Interface | 1x VGA, 1x DP, 1x HDMI | |||
| Touch Interface | 1x USB | ||||
| OSD Control | Function Key | 5 Keys : Menu, Up, Down, Auto Adjust, Monitor Power on/o ff | |||
| Power | Power Connector | 2-Pin Termial Block | |||
| Power Input | 12~24 V DC power input | ||||
| Power Consumption | 1.33A @ 12V (16W) | ||||
| Power Type | 2 pin termianl block | ||||
| Power Adapter | 50 W power adapter, with AC 100~240 V input and DC + 12 V @ 4.17A MAX output | ||||
| Environment | Operating Temperature | 0~50° C (32~122° F) | |||
| Storage Temperature | -30~70° C (-22~158° F) | ||||
| Humidity | 5~95% @ 40° C, Non-condensing | ||||
| Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | ||||
| General | Ingress Protection | IP65, Aluminum front Bezel | |||
| Dimensions (W x H x D) | 561.8 x 352.76 x 53.15 mm (22.11” x 13.88” x 2.09”) | ||||
| Weight | 5.10kg (12.25lb) | ||||
| Operating System | Windows XP/7/8.1/10, WES7-E/P, WE8S, Linux Fedora, Ubuntu | ||||
| Certification | CE, FCC Class A | ||||
Ordering Information
| Part No. | Description |
| TPM-3521RW-A2 | 21.5" 16:9 (1920 x 1080), 250 nits, Aluminum IP65 Front Panel, 5-wire Resistive Touch, USB Interface, 1x DP, 1x HDMI, 1x VGA, DC 12~24V, Phoenix Connector |
Packing List
| Description | |
| 1 x TPM-3521 | |
| 1 x USB Cable | |
| 1 x VGA Cable | |
| 12 x Panel Mount Screws | |
Optional Items
| Part No. | Description |
| ACS-PS-US | Power Cable 3-pin, 180 cm, USA Type |
| ACS-PS-EU | Power Cable 3-pin, 180 cm, Euro Type |
| ACS-PS-CN | Power Cable 3-pin, 180 cm, China Type |
| ACS-100-STD | VESA Table Stand |
