MEGA-3110

MEGA-3110
High-Performance GPU Computer with Intel® 9th / 8th LGA1151 Processors
  • Quote

  • Datasheet

  • Driver

Features
list_dot_01.pngSupports 9th / 8th Intel® Core™-i LGA 1151 Processors
list_dot_01.pngTriple Display Supported by VGA, DVI and Display Port
list_dot_01.pngDual DDR4 2400 MHz SO-DIMM up to 32 GB
list_dot_01.png3 x Intel GbE Ports, Support Wake-on-LAN and PXE
list_dot_01.png2 x Removable 2.5“ SATA HDD Bays and
   2 x Internal 2.5” SATA HDD Bays
   Supporting RAID 0, 1, 5, 10
list_dot_01.png-40 ~ 70°C Operating Temperature
list_dot_01.png2 x CFast / mSATA Sockets
Applications
list_dot_01.pngEdge Computing
list_dot_01.pngTraffic Vision
list_dot_01.pngIntelligent Control
list_dot_01.pngDeep Learning
list_dot_01.pngArtificial Intelligence
list_dot_01.pngVoice Recognition
Model MEGA-3112 MEGA-3113
Processor System CPU Socket 9th/ 8th Intel® Core™ i3 / i5 / i7 Desktop 35W/65W LGA 1151 Processors
Frequency N/A
System Chipset Intel® Q370 Express Chipset
Cache N/A
BIOS AMI BIOS, 256Mbit SPI Flash ROM On Board
Memory Technology Dual Channel DDR4 2400/2666 MHz SDRAM
Max. Capacity 64 GB (Un-buffered and Non-ECC)
Socket 2x DDR4 260-pin SO-DIMM
Display Graphics Engine Integrated Intel® UHD Graphics 630 (Core™ i7/ i5/ i3)
Integrated Intel® UHD Graphics 610 (Pentium/ Celeron)
HDMI N/A
DP 1x DP, up to 4096 x 2160
VGA 1x VGA, up to 1920 x 1200
DVI 1x DVI-D, up to 1920 x 1200
I/O Interface USB 6x USB 3.2 and 2x Internal USB 2.0 Ports
Serial Port 6x COM (RS-232/422/485), with Auto Flow Control, DB9
Ethernet 3x GbE
(LAN1: Intel® i219-LM, Supporting Wake-on-LAN and PXE)
(LAN2/3: Intel® i210-AT GbE, Supporting Wake-on-LAN and PXE)
Audio Lin out, Mic in (Realtek ALC888S)
GPIO / DIO 8x Isolated DI and 8x Isolated DO (2 x 9-Pin Terminal Block)
Antenna Hole 8
Flexible I/O Window Slot 2
Others 1x Removable CMOS Battery and 1x External Clear CMOS Switch
Storage 2.5" HDD / SSD 2x Removable 2.5" SATA HDD Bays and 2x Internal 2.5" SATA HDD Bays
M.2 N/A
CFast/mSATA 2x CFast Sockets (shared by 2x mSATA)
RAID RAID 0, 1, 5, 10
Expansion Mini PCIe 2x Full-size Mini-PCIe Socket (mux with mSATA) and 2x Full-size Mini-PCIe
M.2 N/A
PCI / PCIe 1x PCIe X16 Slot and 1x PCIe X8 Slot (4-Lane) 1x PCIe X16 Slot and 2x PCIe X8 Slot (4-Lane)
SIM Holder 2x External SIM Sockets and 2x Internal SIM Sockets
Power Power Mode AT / ATX
Power Supply Voltage 9~48V DC (without GPU Card)
24~48V DC (with GPU Card)
Connector Type 1x 3-pin Terminal Block Connector with Power Input
Power Ignition Power Ignition Sensing
Power Consumption (Typical) Optional AC/DC 24V, 220W without GPU Card
Optional AC/DC 24V, 500W/1000W with GPU Card
Protection Over Voltage Protection (OVP) up to 52V
Reverse Voltage Protection (RVP) up to -48V
Over Current Protection (OCP) 20A
Car Mode 1x PC/Car Mode Switch
Mounting Type Wall Mount / Stand Mount
Environment Operating Temperature -40~70° C (-40~158° F)
Storage Temperature -40~85° C (-40~185° F)
Humidity 5~95% @ 40° C, Non-Condensing
Vibration 3 Grms, 5-500 Hz, 3 Axis
Shock 30 Grms, Half-sine 11 ms
General Certification CE, FCC Class A
Thermal Dissipation Fan Based System
Material Extruded Aluminum with Heavy Duty Metal
Dimensions (W x H x D) 168 x 241.5 x 356 mm (6.61”x 9.51” x 14.02”) 168 x 241.5 x 356 mm (6.61” x 9.51” x 14.02”)
Net Weight 7.35 kg (16.20 lb) 7.55 kg (16.64 lb)
Operating System Windows 10 (IoT / Professional), Linux

Ordering Information

Part No. Description
MEGA-3112 Intel® 9th/8th Gen. Core™ i LGA1151 CPU, Q370 Fanbased Box PC, 6x USB3.2 ,6x RS232/422/485, 3x GbE, 1xDP, 1x VGA, 1x DVI-D, 2x Flexible I/O Window Slots, 1 PCIeX8 Slot (4-lane), 1x PCIeX16 Slot, 2x Removable 2.5" SATA HDD Bays, 2x Internal 2.5" SATA HDD Bays, Line Out, Mic In, DC 24~48V, Terminal Block Connector
MEGA-3113 Intel® 9th/8th Gen. Core™ i LGA1151 CPU, Q370 Fanbased Box PC, 6x USB3.2, 6x RS232/422/485, 3x GbE, 1xDP, 1x VGA, 1x DVI-D, 2x Flexible I/O Window Slots, 2x PCIeX8 Slots (4-lane), 1x PCIeX16 Slot ,2x Removable 2.5" SATA HDD Bays, 2x Internal 2.5" SATA HDD Bays, Line Out, Mic In, DC 24~48V, Terminal Block Connector

Packing List

Description
1x MEGA-3110 Series Machine
1x Wall Mount Kit

Optional Items

Part No. Description
AWD-4G003 4G(LTE) EG25-G + 2 Antennas, Full Size (for Global)
AWD-4G004 4G(LTE) EC25EFA + 2 Antennas, Full Size (for Europe/Taiwan/China/Hong Kong)
AWD-WF001 Wi-Fi 802.11 b/g/n (1T1R) + 1 Antenna, Half Size
AWD-WF003 Wi-Fi 802.11 a/b/g/n/ac/BT4.0 (2T2R) + 2 Antennas (Dual Band), Half Size
i7-9700TE Intel® Core™ i7-9700TE (8-Cores, up to 3.8 GHz, 35W TDP)
i5-9500TE Intel® Core™ i5-9500TE (6-Cores, up to 3.6 GHz, 35W TDP)
i7-8700T Intel® Core™ i7-8700T (6-Cores ,up to 4.0 GHz, 35W TDP)
i5-8500T Intel® Core™ i5-8500T (6-Cores, up to 3.5 GHz, 35W TDP)
i3-8100T Intel® Core™ i3-8100T (4-Cores, up to 3.1 GHz, 35W TDP)
55400-0000-M5 Power Supply 24V/21A 500W with 4x DC Cables, Phoenix Connector
55400-0001-M5 Power Supply 48V/21A 1000W with 4x DC Cables, Phoenix Connector
30130-0000-CA Power Cord, 3-pin US Type SL-2 + Y, 180 cm
30131-0000-CA Power Cord, 3-pin EU Type SL-6 + Y, 180 cm
