The
BPC-3112 is a compact Box PC with high-performance computing yet lower power
consumption featuring the 12th Gen Intel® Core™ i5-1235U Processor. The processor
combines two types of cores: Performance cores (P-cores) for fast and
responsive tasks, and Efficient cores (E-cores) for handling multiple tasks
smoothly in the background. Whether you're running demanding applications or
multitasking, Intel® Core™
i5-1235U delivers the perfect balance of speed and energy efficiency.
The
BPC-3112 supports up to 64GB of DDR4 3200 MHz RAM and offers dual HDMI
displays. Rich I/O functions include 2 x 2.5GbE LAN, 4 x USB 3.2 Gen 2, 2 x USB
2.0 ports. When it comes to storage ability, BPC-31112 offers one 2.5” SATA HDD
drive and one M.2 M-Key for extensive storage capacity. In addition, this powerful
computing system has great expansions: one Mini-PCIe and one M.2 E-key interface
to install Wi-Fi or 5G/ 4G wireless communication modules. The system also
equipped with 8 x DIO and 4 x COM ports, providing a flexible interface for
interacting with a wide range of external devices and systems.
Designed
for reliability in industrial environments, the BPC-3112 is built to withstand
extreme temperature from -20°C up to 60 °C. The device operates stably with a
fanless design and supports a wide power supply voltage range from 9V to 36V DC
Input with 2-pin phoenix type connector. It also utilizes the Trusted Platform
Module (TPM) 2.0 function onboard to ensure data and network security.
The
ultra-compact and thin exterior design is perfect for the present demanding
embedded and productive applications. The BPC-3112 supports Windows 10 IoT,
Windows 11 (IoT/Professional), and Linux to meet ready-to-market demand and
provide competitive advantages for our customers.
Key Features
 High-performance computing but
low power consumption with Intel® Core™ i5-1235U
Compact and thin design
suitable for embedded applications
Fanless design ensures embedded
solutions
Supports up to 64GB of DDR4
3200 MHz RAM
Dual HDMI displays for
enhanced visual output
Rich I/O interfaces for
flexible integration
Operating temperature from
-20°C to 60°C for harsh environments
9V to 36V DC Input with
2-pin Phoenix type connector
Equipped with Trusted Platform
Module (TPM) 2.0 to enhance data and network security
Applications
Industrial Automation and Control System
The
BPC-3112 can serve as a reliable controller in automated manufacturing
environments, where it can manage PLC, SCADA system, and other machinery. Its
multiple I/O ports, DIO, and COM ports make it ideal for interfacing with sensors,
actuators, and other control systems, ensuring precise and efficient operation.
Edge Computing and IoT Gateway
The
BPC-3112 is an ideal solution for edge computing and IoT gateway applications,
thanks to its powerful Intel® Core™ i5-1235U Processor and extensive
connectivity options. It can efficiently process data at the edge, close to the
source, minimizing the need that sending large amounts of data to the cloud.
This enables real-time analytics, quick decision-making, and reduced latency in
IoT networks. Its fanless, rugged design ensures reliable operation in
challenging environments, making it perfect for smart cities, industrial IoT
deployments, and remote monitoring systems.
Digital Signage and Kiosk
The
dual HDMI display support and high-performance processing make the BPC-3112 an
excellent choice for digital signage and interactive kiosks. It can handle
high-resolution graphics and video playback, providing smooth and responsive
user interactions in retail, transportation, or public information systems.
Surveillance and Security System
The
BPC-3112’s robust processing power and extensive storage options make it ideal
for managing surveillance systems. It can process video feeds, manage multiple
cameras, and run video analytics software for real-time monitoring and security
applications. The TPM 2.0 functionality enhances security, ensuring that
sensitive data remains protected.
|
